Dallara WSL 302

The Dallara World Series Light 2 litre will be a new car based on the F302. The aerodynamics will be developed in the wind tunnel with a goal to gain 25% more of downforce of the F302.

Important changes compared to the F302 car:

- Completely new aerodynamics
- new under wing
- new,and higher side pods
- new rear diffuser
- new engine cover
- new position of Front and Rear wing
- wider bodywork
- New Nylon side skirt on the floor
- 6 speed sequential gearbox
- Wider track front and rear
- Bigger radiators
- different drive shaft and tripod
- different engine installation
- Wheel tethers(wheel saefty cables)

The car will be designed to have the new 2 litre engine prepared by A.E.R.

Technical Chassis Specifications
Type: Pone wheel,single seat,open cockpit.Ground effect stepped plane underbody.Outboard front and rear wings.
Chassis: Composite construction carbon/kevlar/AL-honeycomb
Front suspension: Pushrod and momo damper
Rear suspensionl: Pushrod and twin damper
Weight: 560 kg including driver
Wheelbase: ~2695 mm
Front track: ~1570 mm
Rear track: ~1520 mm
Gearbox: Hewland
Engine suppliers: AER
Rims: Speedline 11" és 12.5"
Brakes: Brembo discs and pads
Std dampers : Koni
steering wheel: Sparco
Fire extinguisher: Lifline
Fuel Cell: Premier
Filters: Fiaam
Battery: Gates
Radiators: Behr
